Manufacturing Facilities
Coreshop Facilities
Ingersoll rand compressor
Shell Core Shooter
Machinery Details
Foundry Facilities
1000 X 800 MM - 2 No.
Electrical Melting Cum Holding Furnace Line
800 X 600 MM-1 No.
Abrasive Belt Grinder
Electrical Furnance
Gavity Die Casting Machine
Rotary Nitrogen D-Gassing Machine
Tilting Machine
Vertical Band Saws Machine
Tool Room and Casting Machining
CNC Machine
Matsuura MC-1500V
Radial Drill Machine
Testing & Measuring Equipments
OPTICAL SPECTROMETER
VERNIER HEIGHT GAUGE (600 MM)
VERNIER CALIPER (600 MM)
SURFACE PLATE-TESTING EQUIPMENT
| SPECIFICATIONS | UNIT | BMV 65+ | BMV 60 | MATSUURA |
|---|---|---|---|---|
| TABLE | mm*mm | 1700*650 | 1200*600 | 1600*650 |
| Max.safe load on table | Kg. | 1500 | 1000 | 1500 |
| TRAVERSE | ||||
| X-AXIS | MM | 1500 | 1050 | 1550 |
| Y-AXIS | MM | 720 | 610 | 670 |
| Z-AXIS | MM | 650 | 610 | 610 |
| FEED | mm/min | 1-10000 | 1-10000 | 1-5000 |
| SPINDLE SPEED | rpm | 8000 | 6000 | 4000 |
| SPINDLE TAPER | BT 40 | BT 40 | BT 40 | |
| ACCURACY | ||||
| POSITIONING | MM | 0.015 | 0.015 | 0.05 |
| REPEATABILITY | MM | 0.009 | 0.009 | 0.05 |
| CNC SYSTEM | MITSUBISHI M70 A | MITSUBISHI M70 A | FIDIA M CLASS |
VMC MACHINES SPECIFICATION
